Line Pipe
Seamless Pipeline, Seamless Line Pipe
Application: For gas, water, transportation in Petroleum and natural gas industries

Special specifications can be customized according to customer requirements, please contact us to explain separately!

Contact us
Line Pipe
Description
Specification
Images

StandardGradeChemical Components (%)Mechanical Properties
CSiMnPSTensile STrength(Mpa)Yield STrength(Mpa)
API 5L PSL1A0.22-0.90.030.03≥331≥207
B0.28-1.20.030.03≥414≥241
X420.28-1.30.030.03≥414≥290
X460.28-1.40.030.03≥434≥317
X520.28-1.40.030.03≥455≥359
X560.28-1.40.030.03≥490≥386
X600.28-1.40.030.03≥517≥448
X650.28-1.40.030.03≥531≥448
X700.28-1.40.030.03≥565≥483
API 5L PSL2B0.24-1.20.0250.015≥414≥241
X420.24-1.30.0250.015≥414≥290
X460.24-1.40.0250.015≥434≥317
X520.24-1.40.0250.015≥455≥359
X560.24-1.40.0250.015≥490≥386
X600.24-1.40.0250.015≥517≥414
X650.24-1.40.0250.015≥531≥448
X700.24-1.40.0250.015≥565≥483
X800.24-1.40.0250.015≥621≥552

API 5L GradeYield StrengthTensile StrengthYield to Tensile RatioElongation
min.min.(max.)min.
(ksi)(ksi)
%
A30480.9328
B35600.9323
X4242600.9323
X4646630.9322
X5252660.9321
X5656710.9319
X6060750.9319
X6565770.9318
X7070820.9317
X8080900.9316


Standard

ASTM A106,A53,A179,A192,A333,A519,A795,A335,A500API 5L, API 5CTJIS

 G3452,G3454,G3455,G3456,G3444,G3460,G3461,G3464

DIN1629,DIN2391EN10210,EN10025GB/T 8163, GB/T 5310,GB/T 3087and so on

Grade

A,B,C,Gr.3,Gr.6P5,P9,P11,P12,P91...PSL1/PSL2 X42,X52,X60,X65,X70,X80

SGP,STPG,STS,STPT,STPL,STB,STBL

ST35,ST37,ST52S235,S275,S355Q235,Q345,10#,20#,45#,16Mn and so on

Wall ThicknessSch10,Sch40,Sch80,Sch160, 2mm - 30mm
Unit length3m, 5.8m, 6m, 11.8m, 12m, 13.5m or as per customers' request
Section ShapeRound
ApplicationFluid Pipe,Water Pipe,API pipe
TechniqueHot Rolled
CertificationISO9001/API/SGS, BV, TUV certificate
Surface TreatmentBare/ Black varnised / oiled ,Hot Dip Galvanized,
Special PipeAPI Pipe
Tolerance±10%
TypeSeamless Steel Pipe
Processing ServiceBending, Punching, Cutting, Grooved ends, Screwed ends, galvanised
EndsBevel ends, Plain ends, Grooved ends, Screwed ends
End protectorPVC Caps
PackingBundles with PVC wrapped


Tolerance on Dimensions

StandardOut DiameterWall Thickness
API 5LToleranceTolerance
D<60.3+0.41mm, -0.80mm+15.0%, -12.5%
D≥60.3+0.75%D, -0.75%D+15.0%, -12.5%


展示1
